Hikmicro -“Lynx Pro 10mm (LE10)”

£599.99

Hikmicro -“Lynx Pro 10mm (LE10)”

In stock

Description

Hikmicro -“Lynx Pro 10mm (LE10)”

Joining the range of HIK Micro thermal monoculars – the Lynx LE10 is focused on delivering high-level thermal performance at an entry-level price point.

At the heart of this enhanced performance is the 256 x 192, 12um sensor, this delivers higher levels of image detail that will be especially useful when trying to locate and identify small animals like rabbits, squirrels and birds. The sub 35 NETD performance of the sensor ensures detection of small temperature changes and excellent performance in harsh conditions.

The Lynx 10mm offers the same software as the more expensive HIK models and includes 4 colour palettes, white-hot, black hot, red hot and fusion. The LE10 can also record video or images with the onboard memory or connect to the T-Vision app to seamlessly share or record your shooting experience.

The fixed-focus optical system and wide field of view make it easy to quickly scan large areas and identify them.

MAIN UNIT DATA

Sensor – 160x120px @ 17µm 256x192px @ 12µm
Objective Lens (Focal Length) – 6 mm 10 mm
Detection Range (Human 1.8 x 0.5m) – 182 m / 458 m

SENSOR

Type – VOx Uncooled Focal Plane Arrays

VOx Uncooled Focal
Plane Arrays
Resolution, pixels – 256 x 192 PX

Pixel pitch, µm –
Frame rate, Hz – 50 Hz/25 Hz
NETD – <35mK – <35mK

OPTICS

Objective lens – F1.1 – F1.0
Magnification (Digital) – 1x, 2x, 4x, 8x
Field of view – 24.7° × 18.00° × 13.55° (H × V)°

DISPLAY

Type
5.08mm, LCOS
Resolution, Pixels – 720 × 540
Colour Palettes
Black Hot, White Hot, Red Hot, Fusion

Additional features

Hot Tracking- YES
WiFI hot spot – YES
T-Vision App support – YES

 Environmental
Degree of protection, IP code – IP67
Dust protection – Protected against dust ingress
Water protection – Protected against temporary submersion in water
Operating temperature range – -20 °C to 55 °C

WEIGHT & SIZE

Dimensions, mm
158 mm x 61 mm x 57 mm
Weight, kg – 0.26 kg

 POWER SUPPLY

Operating time on battery
(WiFi & Hot tracking disabled) – 8 Hours continuous running
Charging interface
USB-C
Battery capacity after 1000 cycles – 80%

Warranty Period
Main Unit
Battery
3 Years
2 Years
SKU – HM-LE10

Additional information

Brand

Hik

Condition

New

Magnification

8x
